CZ6478/121B Explosion-proof light fittings LED(Wide beam, Narrow beam, Street light beam)

Prodcuts Features:

● It is long life and maintenance-free which the service life is up to 50000 hours and the maintenance-free of long term.

● There is a feature of good electromagnetic compatibility and it does not cause interference to the system power grid.

● It is not influenced by the voltage fluctuations and can be operated in the wide voltage range of 100 ~ 240V AC.

● LED is soild light source with great anti-knock performace convenient for installation and maintainence

● The degree of protection is up to IP66.

● IECEx and ATEX certified.

● Customized high light efficiency light source with light efficiency ≥ 135ml/w(Meet China's first-class energy efficiency standards)

● Can be combined to meet user different and various requirement.

Product Parameter

Product type:

LED Explosion-proof light fittings(Wide beam, Narrow beam, Street light beam)

Certification:

China IECEX ATEX

Application range (zones):

 2G/Gb/zone 1;2D/Db/zone 21

Min.ambient temperature:

T6:-60℃/ -40℃

Max.ambient temperature:

T6:+40℃ T5:+55℃

Degree of protection:

 IP66

Rated voltage:

 100V~240V AC   50/60Hz

Color temperature:

Standard 5000K,(Optional 3000K,4000K,6500K)

Material of enclosure:

Aluminum alloy / tempered glass (transparent lampshade)

  • Main technical data
  • Optional Ex components
  • Video
  • Accessorise
  • Download
  • Certification: China:Ex db IIB+H2 T6/T5/T4 Gb   Ex tb IIIC T80°C/T90°C/T95°C/T105°C Db

    IECEx: Ex db IIB+H2 T6/T5/T4 Gb   Ex tb IIIC T80°C/T90°C/T95°C/T105°C Db

    ATEX:    II 2GD  Ex db IIB+H2 T6/T5/T4 Gb   Ex tb IIIC T80°C/T90°C/T95°C/T105°C Db
    Intended use: Can be used in zone 1 and zone 2
    Can be used in zone 21 and zone 22
    Ambient temperature: -40°C≤Ta≤+40°C/+55°C
    -60°C≤Ta≤+40°C/+55°C
    (-60°C lamp electrical equipment need to be customized)
    Degree of protection: IP66
    Rated voltage: 100V~240V AC   50/60Hz
    Color temperature:  Standard 5000K, (Optional 3000K,4000K,6500K)
    Power factor: λ>0.95
    Terminals: L1, N cage type terminal 2×1~2.5mm², PE terminal: 2×2.5~6mm²
    Cable entry: 1-M25×1.5, outside diameter: Φ12-19mm(CZ1725/1A)
    1-M25×1.5  stopping plug(CZ1725/3A)
