CZ1390 Explosion-proof distribution panel (Moveable)

Prodcuts Features:

● The distribution box could be portable or movable, which is easy to use.
● Equipped with electrically conductive thermoplastic rubble wheels (remove static electricity)
● Besides available standard configuration, also could do customization based on requirements.
● Degree of protection up to IP65/IP66
● IECEx International Approval, ATEX European Approval.

Product Parameter

Product type:

Explosion-proof distribution panel ( Moveable)

Certification:

CCC IECEX ATEX

Application range (zones):

2G/Gb/zone 1;2D/Db/zone 21

Min.ambient temperature:

-40℃

Max.ambient temperature:

+55℃

Degree of protection:

IP66 / IP65

Rated voltage:

220/230V  AC

Rated cuttrny:

16A

Frequency:

50/60Hz

Material of enclosure:

304/316L stainless steel

Material of moveable trolley:

304 stainless steel
